Annulus Pressure Operated Test Tools

This is a series of full-bore, annulus pressure-operated tools used in cased-hole testing, including packers, circulating valves, test valves and other auxiliary tools. The series can be used for testing, perforating + testing, and perforating + acid fracturing + testing operations.

Long Long Slip Joint

Compensates for vessel heave and thermal and pressure effects on the string

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

Extension Pipe

Accommodates string length changes and absorbs perforating shock

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

FLAPPER Pressure Test Valve

Full-bore valve for repeated pressure testing of the work string while tripping in

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

AP FLAPPER Pressure Test Valve

Rupture-disc operated flapper valve for repeated pressure testing while tripping in

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

AP Bypass Pressure Test Valve

Full-bore pressure test valve and bypass valve in one tool

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

APS Circulating Valve & AP Circulating Valve

Single-shot safety circulating valve for the end of a well test

Tool sizes: 3⅛, 3⅞, 5 in Working pressure: 10,000, 15,000 psi

HPAPS Circulating Valve & HPAP Circulating Valve

High-pressure safety circulating valves for deep wells

Tool sizes: 3⅛, 3⅞, 5 in Working pressure: 15,000 psi

FLAPPER Circulating Valve

Safety valve, squeeze valve and circulating valve in one tool

Tool sizes: 5 in Working pressure: 10,000, 15,000 psi

Needle-type Drain Valve

Recovers the fluid sample trapped between two ball valves at surface

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

Sleeve-type Drain Valve

Transfers the sample trapped between two closed ball valves

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

SIERRA Multi Circulating Valve

Annulus pressure-operated circulating valve that opens and closes repeatedly

Tool sizes: 3⅛, 3⅞, 5 in Working pressure: 10,000, 15,000 psi

MAIN Test Valve

Annulus pressure-operated downhole test valve for repeated open/close

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

KIKO Locked-open Test Valve

Test valve that opens and closes repeatedly and locks open without holding annulus pressure

Tool sizes: 3⅞, 5 in Working pressure: 15,000 psi

Locked-open Test Valve for Shallow Wells

Simple lock-open test valve for wells with hydrostatic pressure below 5,500 psi

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

Select Test Valve

Multi-cycle test valve with switchable standard and locked-open modes

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

AP Open-Shut Off Valve

Single open/close cycle valve with circulation after shut-in

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

AP Shut-Off Valve & AP Open Valve

One-time full-bore valves that together complete one open/close cycle

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

AP Sampler

Full-opening sampler that captures formation fluid downhole

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

Gauge Carrier

Carrier for downhole pressure and temperature gauges, designed to suit the gauge

Tool sizes: As required in Working pressure: 10,000, 15,000 psi

HAMMER Jar

Full-bore hydraulic jar for freeing a stuck testing string

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

TRUST Safety Joint & Fishing Tool

Releases the string above a stuck packer and recovers the stuck part

Casing sizes: 4½–5, 5½, 7, 9⅝ in casing Working pressure: 10,000, 15,000 psi

Fishing Tool

Retrieves the stuck part below a released TRUST safety joint

TRUST Circulating Valve

Locked-open / locked-closed circulating and bypass valve for the TRUST packer

Casing sizes: 4½–5, 5½, 7⅝, 9⅝ in casing Working pressure: 10,000, 15,000 psi

SSD Hydraulic Circulating Valve

Weight-operated bypass / circulating valve with hydraulic delay

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000 psi

MRO Storm Valve

Temporary well shut-in valve for storms and surface maintenance

Tool sizes: 5, 6¼ in Working pressure: 10,000 psi

TRUST Packer

Large-bore retrievable hookwall packer for testing, treating and squeezing

Casing sizes: 4½, 5, 5½, 6⅝, 7, 7⅝, 8⅝, 9⅝, 10¾, 13⅜ in casing Working pressure: 10,000, 5,000 psi

MR Packer

High-strength retrievable packer for perforating + acidizing + testing

Casing sizes: 6⅝, 7 in casing Working pressure: 15,000 psi

MP Packer

Retrievable packer with built-in concentric bypass

Casing sizes: 7, 9⅝ in casing Working pressure: 10,000, 15,000 psi

Safety Joint Below TRUST Packer

Releases a stuck perforating gun below the packer

Tool sizes: 3⅛, 3⅞, 5 in Working pressure: 10,000, 15,000 psi

BSN-3 Safety Valve

Master valve that controls well flow and can cut wireline and coiled tubing

Tool sizes: 8 in Working pressure: 15,000 psi

Internal Pressure Operated Circulating Valve

Full-bore circulating valve opened by internal differential pressure

Tool sizes: 3⅞, 5 in Working pressure: 10,000, 15,000, 12,300 psi
